Thermidor Chill HM - Insulated Hinged Monobloc Chiller Door

Verified by manufacturer 5 months ago

Tekta UK Third party certifications:
  • Alcumus SafeContractor

    Alcumus SafeContractor

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • Constructionline Gold

    Constructionline Gold

    Certificate type

  • CHAS

    CHAS

    Certificate type

The Thermidor Chill HM is a specialist hinged chiller door, designed to provide superior insulation performance for openings in chiller environments.

Jump to:
+ (44) 0330 7000 333 Website

Application

  • Storage Chillers.
  • Defrosting Chillers.
  • Food Factories.
  • Pharmaceutical Factories.

Description

This door range offers a simple and reliable operation and is available with a range of ironmongery to suit site requirements.


With options of different panel thicknesses, high quality rubber seals and optional heated frames / thresholds, this door range is designed to reduce costs and improve safety by optimizing insulation and improving temperature control.


Available with a range of hygienic finishes, including stainless steel, brushed stainless steel and powder-coating, the door is suitable for use in food factories, including wash-down areas.


The door panel is a monobloc design with a welded steel envelope and injected foam core. This offers exceptional stability and insulation performance, with no cold bridges. The fully welded and seamless finish is far superior to alternative designs that use a two part leaf design where water ingress can occur over time, damaging the leaf construction.


Features and benefits:

  • Superior insulation performance.
  • High quality perimeter seals.
  • Safe and reliable operation.
  • Monobloc door leaf design.

General information

Color

White

Silver

Finish

Powder-coated

Stainless steel

Material

Steel

Guidance for specification option:

zinc coated galvanized 0.75 mm.


Polyurethane

Stainless steel

Shape

Square

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

One year

Uniclass

Pr_30_59_24_52 Carbon steel doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

Specification data - Carbon steel doorsets

Configuration

Single-leaf, single-action.

Manufacturer guidance

Structural opening dimensions and number of leaves as per door.

Doorset size

-

Manufacturer guidance

Size (w x h): 3000 x 3000 mm. Other sizes available on request. Insert requirements.

Frame

-

Material

Robust steel frame construction, suitable for industrial environments.

Perimeter seals or inserts

Two-part rubber seal situated between the door frame and leaf to eliminate thermal bridging.

Door leaf

-

Thickness

60 mm.

80 mm.

Manufacturer guidance

Other sizes available on request.

Core

Fully welded steel leaf, injected with a CFC-free polyurethane foam.

Material

Zinc-coated galvanized 0.75 mm.

Finish

-

Coating

Powder coated.

Internal colour

As External.

Hardware

Slam lock and pull handle.

Guidance for specification option:

Standard.

Rod control system.

Guidance for specification option:

For larger door sizes. Optional.

Specialist drop hinge system for superior threshold sealing.

Accessories

Internal emergency escape activation.

Activation

Manual operation.

Guidance for specification option:

Standard.

Automatic closing via a heavy duty industrial door closer.

Guidance for specification option:

Optional.

Sustainability data

Material

Steel

Guidance for specification option:

zinc coated galvanized 0.75 mm.


Polyurethane

Stainless steel
